Plate Type PP Filter Press

Name: Plate Type PP Filter Press
Brand: SHIVA GLOBAL ENVIRONMENTAL PRIVATE LIMITED
Price: 63000 INR
Availability: InStock

63000 INR/Piece

Get a Price/Quote

Product Details:

Ph Level 2-12
Pump Type Slurry/Feed pump (Centrifugal, Diaphragm options)
Water Out Conductivity 10 S/cm
Flow Rate Depends on plate size and system, typical 500-5000 L/h
Recycle Rate Up to 98%
Efficiency (%) Up to 95%
Usage & Applications Industrial liquid-solid separation, wastewater treatment, chemical, pharmaceutical, food and beverage
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Plate Type PP Filter Press Price And Quantity

Minimum Order Quantity 1 Piece
Price 63000 INR/Piece

Plate Type PP Filter Press Product Specifications

Water Source Industrial process water, wastewater
Noise Level 65 dB
Feature Corrosion resistant, easy operation, strong structure
Capacity 5-200 TPD (customizable)
Installation Type Floor-Mounted
Frequency 50/60 Hz
Drive Type Hydraulic/Manual
Water in conductivity 2000 S/cm
Power Consumption Low, approx. 1-5 kW (depending on model)
Product Type Plate Type PP Filter Press
Usage & Applications Industrial liquid-solid separation, wastewater treatment, chemical, pharmaceutical, food and beverage
Efficiency (%) Up to 95%
Filter Type Plate and Frame Filter
Material Polypropylene (PP)
Technology Pressure Filtration
Voltage 220V / 380V, 50/60Hz
Power Source Electric
Volume Customizable according to plate size and number
Recycle Rate Up to 98%
Water Out Conductivity 10 S/cm
Flow Rate Depends on plate size and system, typical 500-5000 L/h
Automatic Grade Manual,Automatic,Semi-Automatic
Pump Type Slurry/Feed pump (Centrifugal, Diaphragm options)
Purity Level High filtration purity (varies with application)
Ph Level 2-12

Weight Varies with model and configuration
Service Life Long, subject to maintenance
Operating Temperature Up to 80C
Sealing Type Gasket/O-ring sealed
No. of Plates 10-100 (customizable)
Filtration Area 1-100 m2 (customizable depending on plates)
Discharge Type Automatic or Manual
Cake Thickness 25-40 mm
Transport Package Wooden case or as required
Plate Size 470 mm x 470 mm, 630 mm x 630 mm, 800 mm x 800 mm, or as required
Max Working Pressure 0.6-1.2 MPa
Color White/Blue/Custom (as per order)
Control System Electro-mechanical

Product Description

Access a peerless solution to industrial filtration with our acclaimed Plate Type PP Filter Press, astonishingly engineered for phenomenal performance across sectors. With customizable plate sizes ranging from 470 mm to 800 mm and up to 100 plates, you can procure a majestic filtration area tailored to your requirements (1-100 m2). Built from corrosion-resistant polypropylene, it handles temperatures up to 80C and offers automatic or manual discharge. Take command with an electro-mechanical control system and benefit from high-efficiency, low power consumption, and a service life that stands out in the industry.

Optimized Usage for Diverse Surfaces & Exclusive Features

This Plate Type PP Filter Press excels in industrial liquid-solid separation, wastewater treatment, chemical processing, pharmaceuticals, and food & beverage applications. It is designed for floor-mounted use, adapting seamlessly to varied operational environments. Enhanced features include adjustable plate and cake thickness, corrosion resistance, and strong structure. The automatic or manual discharge choice, along with easy operation and robust sealing system, render it exceptionally adaptable for both intensive and routine industrial processes.

Certifications, Port of Dispatch & Payment Options

Estimate reliable performance with our certified Plate Type PP Filter Press, compliant with global industry standards. Our export operations are efficiently managed, with delivery from major Indian FOB ports ensuring timely shipment. We offer flexible payment terms such as L/C, T/T, and other secure modes to facilitate a smooth transaction experience. Inquire now to receive a tailored offer and detailed estimate for your order, ensuring transparency and satisfaction with every purchase.

FAQ's of Plate Type PP Filter Press:

Q: How does the Plate Type PP Filter Press work in industrial applications?

A: The filter press separates solids from liquids through pressure filtration, utilizing polypropylene plates and a robust sealing system. It can process a variety of industrial fluids efficiently.

Q: What are the main benefits of using this PP Filter Press?

A: You benefit from a high filtration efficiency (up to 95%), low power consumption, easy operation, and strong resistance to corrosion. Customization options ensure the press meets unique process needs.

Q: When should I choose automatic or manual discharge?

A: Automatic discharge is ideal for high-throughput operations requiring minimal human intervention, while manual discharge suits lower volume applications or tighter budget scenarios.

Q: Where can the filter press be installed?

A: The press is floor-mounted and suitable for installation in industrial plants, wastewater facilities, chemical manufacturing units, and food or pharmaceutical production environments.

Q: What is the process for ordering and delivery?

A: After receiving your specifications, we estimate costs and delivery time. The press is packed as per requirements and shipped from major Indian FOB ports. Delivery is scheduled upon order confirmation.
