Dissolved Air Flotation DAF

Name: Dissolved Air Flotation DAF
Brand: SHIVA GLOBAL ENVIRONMENTAL PRIVATE LIMITED
Price: 750000 INR
Availability: InStock

750000 INR/Piece

Get a Price/Quote

Product Details:

Automation Grade Semi-Automatic to Automatic
Power 2.2 to 7.5 kW (Depending on model)
Treatment Technique Dissolved Air Flotation (DAF)
Flow Rate 30 m3/hr (Typical)
Capacity 10 to 100 m3/hr (Model dependent)
Material Mild Steel & FRP Coating
Installation Type Containerized
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Dissolved Air Flotation DAF Price And Quantity

Price 750000 INR/Piece

Dissolved Air Flotation DAF Product Specifications

Power Source Electric
Power 2.2 to 7.5 kW (Depending on model)
Dimension (L*W*H) 3200 mm x 1850 mm x 2100 mm (Typical)
Treatment Technique Dissolved Air Flotation (DAF)
Technology DAF Clarification
Product Type Dissolved Air Flotation DAF
Automation Grade Semi-Automatic to Automatic
Water Source Industrial Effluent
Operation Type Automatic
Installation Type Containerized
Pressure 0.5 - 0.7 MPa
Ph Level 6.5 - 8.5
Application Wastewater Treatment, Sludge Separation
Material Mild Steel & FRP Coating
Weight 850 kg (Approx.)
Capacity Intel Flow Rate As per requirement
Color blue
Flow Rate 30 m3/hr (Typical)
Capacity 10 to 100 m3/hr (Model dependent)

Electrical Connection 380V, 50Hz, 3 Phase
Sludge Discharge Manual/Automatic
Discharge Outlet Diameter DN80 - DN150
Inlet Solid Concentration <1000 mg/L
Noise Level <75 dB
Design Lifetime >10 Years
Water Quality After Treatment SS <30 mg/L, COD Removal > 60%
pH Resistance Up to 9.0
Air Dissolving Efficiency 90-95%
Skid Mounted Option Available
Float Removal Mechanism Chain Scraper
Tank Type Rectangular

Product Description

Discover peerless industrial wastewater treatment with our Dissolved Air Flotation (DAF) system, designed for superior performance. With air dissolving efficiency of 90-95% and a robust chain scraper float removal mechanism, this DAF ensures potent sludge separation and effluent clarity. Engineered to thrive with competitive pricing, it offers a bargain for exporters, manufacturers, suppliers, and service providers alike. Enjoy the benefits of instant checkout and a user-friendly, skid-mounted, or containerized installation. With a design lifetime over 10 years, this DAF unit stands out for reliability and efficiency.

Dissolved Air Flotation DAF: Usage & Application Scope

The Dissolved Air Flotation (DAF) system is suitable for treating industrial effluent, especially where solids and oils need separation. Its application spans food processing plants, textile units, chemical factories, and municipal wastewater sites. Highly effective in sludge separation, it's ideal for facilities requiring stringent suspended solids (SS) and COD removal, offering reliable operation across diverse sectors in India and abroad. Automatic or semi-automatic operations ensure ease of use and adaptability to varied flow requirements.

Reliable DAF Supply Ability and Payment Flexibility

Our Dissolved Air Flotation (DAF) system enjoys strong supply ability and reliable transport services, ensuring timely delivery of shipped goods anywhere in India or for export. Goods transport is streamlined for both bulk and customized orders. Payment terms are flexible, catering to varied customer needs. Sample units are available on request, allowing you to assess performance before bulk purchase. Trust in our robust support for manufacturers, traders, and service providers seeking reliable solutions.

FAQ's of Dissolved Air Flotation DAF:

Q: How does the Dissolved Air Flotation (DAF) system achieve superior water treatment results?

A: The DAF system uses advanced dissolved air technology, achieving air dissolving efficiency of 90-95%. This results in potent separation of suspended solids, reducing SS to below 30 mg/L and removing over 60% of COD from industrial wastewater.

Q: What industries or applications are best suited for this DAF system?

A: This DAF system is ideal for industrial effluent treatment in sectors like textiles, food processing, chemicals, and municipal facilities requiring efficient sludge separation and water clarification.

Q: Where can this DAF system be installed, and what are the installation options?

A: The system supports versatile installation, being both skid-mounted and containerized, making it suitable for factories, treatment plants, or remote sites with space and mobility requirements.

Q: What is the process for purchasing and receiving the DAF unit?

A: Customers benefit from instant checkout options and competitive pricing. Orders are processed promptly, shipped using secure transport services, with sample availability for evaluation before large-scale purchases.

Q: What are the operational and maintenance benefits of this DAF system?

A: With automation grades ranging from semi-automatic to automatic and a design lifetime exceeding ten years, the system ensures minimal manual intervention, consistent performance, and reduced operational costs.
